Interlake/Mecalux Pallet Rack Pricing & Shipping Locations
Roll-formed selective pallet rack is the most popular and versatile racking in the industry. It offers the best solutions for warehouses with palletized products and a wide variety of goods.
Advantages
Interlake Mecalux selective pallet rack is available with either bolted or welded frames. The company’s patented beam-to-frame connection creates the most rigid and reliable structure available. It also provides exceptional protection against damage, tampering and accidental disengagement.
The company uses only high-strength steel certified to meet the strictest specifications. All weld operations are controlled through advanced robotics or performed by welders certified to AWS Standards. The durable powder coating and baked enamel finishes ensure long life under even the most demanding conditions.
Selective pallet rack can be configured for a variety of uses. Double-depth racks can be installed for increased storage capacity which allows one pallet to be stored in front of another on each side of the aisle. It can also be used in the construction of rack supported buildings. Visit our Needs Profiler tool to help define your unique material handling requirements.
Interlake Mecalux Quick Ship
Our most popular selective pallet rack components are available for quick and cost-effective delivery to all points in North America through our Quick Ship program. Contact Us for more information.
Step Beam – Teardrop Style
| Beams | Teardrop Style – Orange Beams | ||||||
|---|---|---|---|---|---|---|
| Capacity Lbs. | Description (All beams 2.75” W w/ 1.625” Step Ledge | Part # | Sale Price | Weight ea. | Freight Class | Purchase |
| 5,627 | Step Beam, 48” Long x 2-3/4” Face | U0098836 | $16.04 | 12.09lbs | 65 | |
| 4,120 | Step Beam, 96” Long x 3-21/32” Face | U0072457 | $29.03 | 23.11lbs | 65 | |
| 5,048 | Step Beam, 96” Long x 4” Face | U0072471 | $29.633 | 24.26lbs | 65 | |
| 6,036 | Step Beam, 96” Long x 4-1/2” Face | U0072483 | $33.57 | 26.01lbs | 65 | |
| 7,061 | Step Beam, 96” Long x 5” Face | U0074179 | $33.83 | 27.69lbs | 65 | |
| 4,046 | Step Beam, 108” Long x 4” Face | U0072472 | $35.47 | 26.98lbs | 65 | |
| 5,339 | Step Beam, 108” Long x 4-1/2” Face | U0072485 | $37.34 | 28.94lbs | 65 | |
| 6,324 | Step Beam, 108” Long x 5” Face | U0074181 | $37.63 | 30.84lbs | 65 | |
| 4,368 | Step Beam, 120” Long x 4-1/2” Face | U0072486 | $41.14 | 31.88lbs | 65 | |
| 6,779 | Step Beam, 120” Long x 5-15/16” Face | U0074193 | $46.67 | 36.17lbs | 65 | |
| 5,233 | Step Beam, 144” Long x 5-15/16” Face | U0072532 | $55.37 | 42.90lbs | 65 | |
| 6,669 | Step Beam, 144” Long x 6-9/16” Face | U0072541 | $65.63 | 48.93lbs | 65 | |
Teardrop Style Bolted Upright
| eardrop Style Bolted Uprights | 36” Deep | 42” Deep | 48” Deep | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Capacity @48” | Description | Color | Part# | Sale | Weight | Part# | Sale | Weight | Part# | Sale | Weight |
| 15,700 | Teardrop Upright 8′ High | Blue | T0110374 | $57.00 | 41.52 | T0110376 | $58.00 | 43.24 | T0110378 | $58.00 | 44.94 |
| 15,700 | Teardrop Upright 8′ High | Green | T0110375 | $60.12 | 41.52 | T0110377 | $63.83 | 43.24 | T0110379 | $58.00 | 44.94 |
| 15,700 | Teardrop Upright 10′ High | Blue | T0110386 | $69.00 | 52.25 | T0110388 | $75.00 | 54.33 | T0110390 | $76.00 | 56.37 |
| 15,700 | Teardrop Upright 10′ High | Green | T0110387 | $69.00 | 52.25 | T0110389 | $75.00 | 54.33 | T0110391 | $76.00 | 56.37 |
| 15,700 | Teardrop Upright 12′ High | Blue | T0110398 | $85.00 | 60.35 | T0110400 | $89.00 | 62.5 | T0110402 | $89.00 | 64.28 |
| 15,700 | Teardrop Upright 12′ High | Green | T0110399 | $85.00 | 60.35 | T0110401 | $89.00 | 62.5 | T0110403 | $89.00 | 64.28 |
| 18,100 | Teardrop Upright 14′ High | Blue | T0110338 | $104.32 | 70.67 | T0052373 | $111.20 | 72.94 | T0052388 | $114.48 | 75.27 |
| 18,100 | Teardrop Upright 14′ High | Green | T0110339 | $104.32 | 70.67 | T0080134 | $111.20 | 72.94 | T0080135 | $114.48 | 75.27 |
| 18,100 | Teardrop Upright 16′ High | Blue | T0110350 | $111.51 | 78.21 | T0052375 | $118.43 | 80.42 | T0052390 | $121.75 | 82.7 |
| 18,100 | Teardrop Upright 16′ High | Green | T0110351 | $111.51 | 78.21 | T0080140 | $118.43 | 80.42 | T0080141 | $121.75 | 82.7 |
| 22,700 | Teardrop Upright 12′ High | Blue | T0110446 | $95.00 | 77.99 | T0110448 | $106.00 | 80.85 | T0110450 | $110.00 | 83.77 |
| 22,700 | Teardrop Upright 12′ High | Green | T0110447 | $95.00 | 77.99 | T0110449 | $106.00 | 80.85 | T0110451 | $110.00 | 83.77 |
| 22,700 | Teardrop Upright 16′ High | Blue | T0110470 | $125.71 | 101.95 | T0110472 | $129.00 | 105.56 | T0110474 | $135.00 | 109.25 |
| 22,700 | Teardrop Upright 16′ High | Green | T0110471 | $125.71 | 101.95 | T0110473 | $129.00 | 105.56 | T0110475 | $135.00 | 109.25 |
| 22,700 | Teardrop Upright 18′ High | Blue | T0110482 | $141.65 | 111 | T0110484 | $149.00 | 114.57 | T0110486 | $159.00 | 118.24 |
| 22,700 | Teardrop Upright 18′ High | Green | T0110483 | $141.65 | 111 | T0110485 | $149.00 | 114.57 | T0110487 | $159.00 | 118.24 |
| 22,700 | Teardrop Upright 20′ High | Blue | T0110494 | $157.31 | 122.92 | T0110296 | $161.00 | 126.89 | T0110498 | $165.00 | 130.93 |
| 22,700 | Teardrop Upright 20′ High | Green | T0110495 | $157.31 | 122.92 | T0110497 | $161.00 | 126.89 | T0110499 | $165.00 | 130.93 |
| Accessories | |||
|---|---|---|---|
| Description | Part# | Price | Weight |
| 6” Row Spacer w/ Hardware (Galvanized) | 47972 | $5.62 | 1.1 |
| 6” Row Spacer w/ Hardware (Galvanized) | 47972 | $5.62 | 1.1 |
| 10” Row Spacer w/ Hardware (Galvanized) | 47974 | $6.03 | 1.5 |
| 12” Row Spacer w/ Hardware (Galvanized) | 47975 | $6.29 | 1.8 |
| Wall Connector w/ Hardware | 32374 | $1.83 | 0.5 |
| Pallet Support/Crossbar, 36”, 1,810lbs Cap | 72728 | $7.22 | 4.3 |
| Pallet Support/Crossbar, 42”, 1,520lbs Cap | 72729 | $8.37 | 4.98 |
| Pallet Support/Crossbar, 48”, 1,310lbs Cap | 72731 | $9.46 | 5.66 |
| Column Protector U80, 16” High (Orange) | 34147 | $31.35 | 15.1 |
| Shims U77 | 53005 | $1.71 | 0.5 |
| Anchor Bolts 1/2” x 4-1/4” | 34139 | $1.86 | 0.22 |
| Step- Beams (Orange) | Non Slotted (2 in pos.15) | Slotted (4 in pos.15) | |||||
|---|---|---|---|---|---|---|---|
| Capacity | Description (All beams 2.75” wide w/ 1.625” step ledge) | Part # | Net $ Ea. | Weight | Part # | Net $ Ea. | Weight |
| 5,627 | IB27EH04800RCA_000 Step Beam (2-3/4” Face) 4′ Long | U0098836 | $15.50 | 11.24lbs | N/A | N/A | |
| 4,120 | IB36EH09600RCA_000 Step Beam (3-21/32” Face) 8′ Long | U0072457 | $29.00 | 23.11lbs | U0072466 | $29.00 | 22.65lbs |
| 5,058 | IB40EH09600RCA_000 Step Beam (4” Face) 8′ Long | U0072471 | $29.50 | 24.26lbs | U0072477 | $29.50 | 23.79lbs |
| 6,036 | IB45EH09600RCA2000 Step Beam (4-1/2” Face) 8′ Long | U0072483 | $34.00 | 26.01lbs | N/A | ||
| 7,061 | IB50EH09600RCA_000 Step Beam (5” Face) 8′ Long | U0074179 | $35.00 | 27.69lbs | U0074185 | $35.00 | 27.22lbs |
| 4,046 | IB40EH10800RCA2000 Step Beam (4” Face) 9′ Long | U0072472 | $34.50 | 26.98lbs | |||
| 5,339 | IB45EH10800RCA2000 Step Beam (4-1/2” Face) 9′ Long | U0072485 | $36.00 | 28.94lbs | |||
| 6,324 | IB50EH10800RCA_000 Step Beam (5” Face) 9′ Long | U0074181 | $36.50 | 30.84lbs | U0074187 | $36.50 | 30.32lbs |
| 4,368 | IB45EH12000RCA2000 Step Beam (4-1/2” Face) 10′ Long | U0072486 | $39.50 | 31.88lbs | |||
| 5,615 | IB50EH12000RCA4000 Step Beam (5” Face) 10′ Long | N/A | —- | U0074188 | $43.00 | 33.41lbs | |
| 6,779 | IB59EH12000RRA2000 Step Beam (5-15/16” Face) 10′ Long | U0072530 | $52.00 | 38.72lbs | |||
| 5,233 | IB59EH14400RRA4000 Step Beam (5-15/16” Face) 12′ Long | N/A | —- | U0072537 | $58.00 | 45.12lbs | |
| 6,669 | IB65EH14400RRA2000 Step Beam (6-9/16” Face) 12′ Long | U0072541 | $65.00 | 48.93lbs | |||
| Teardrop Style Uprights – Welded Frames | 36” Deep | 42” Deep | 48” Deep | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Capacity | Frames (48” Shelf Spacing) | Part # | Net $ Ea. | Weight | Part # | Net $ Ea. | Weight | Part # | Net $ Ea. | Weight |
| 19,300 | IE025F096 96” High Uprights | U0072747 | $72.00 | 42.50lbs | U0072748 | $75.00 | 45.15lbs | U0072750 | $79.00 | 47.78lbs |
| 19,300 | IE025F120 120” High Uprights | U0072751 | $83.00 | 53.26lbs | U0072752 | $89.00 | 55.90lbs | U0072754 | $89.00 | 58.53lbs |
| 19,300 | IE025F144 144” High Uprights | U0072755 | $99.00 | 64.01lbs | U0072756 | $105.00 | 66.65lbs | U0072758 | $110.00 | 69.20lbs |
| 19,300 | IE025F192 192” High Uprights | U0072764 | $140.00 | 88.14lbs | ||||||
| 19,300 | IE025F240 240” High Uprights | U0072772 | $175.00 | 109.64lbs | ||||||
| 30,600 | IE075F144 144” High Uprights | U0072984 | $130.00 | 83.67lbs | ||||||
| 30,600 | IE075F192 192” High Uprights | U0072992 | $175.00 | 110.25lbs | ||||||
| 30,600 | IE075F216 216” High Uprights | U0072996 | $185.00 | 123.55lbs | ||||||
| 30,600 | IE075F240 240” High Uprights | U0073000 | $215.00 | 136.84lbs | ||||||
| Accessories | |||
|---|---|---|---|
| Description | Part# | Price | Weight |
| 6” Spacer | U0075880 | $8.50 | 1.19lbs |
| 8” Spacer | U0075882 | $9.50 | 1.43lbs |
| 10” Spacer | U0075883 | $10.00 | 1.70lbs |
| 12” Spacer | U0075884 | $11.00 | 1.91lbs |
| 6” Wall Tie | U0075993 | $3.50 | 1.08lbs |
| 12” Wall Tie | U0075995 | $4.50 | 1.66lbs |
| Roll-in Cross Bar 36” | U0072732 | $5.50 | 3.19lbs |
| Roll-in Cross Bar 42” | U0072733 | $6.50 | 3.79lbs |
| Roll-in Cross Bar 48” | U0072735 | $7.50 | 4.39lbs |
| Flanged Cross Bar 36” | U0072728 | $6.50 | 4.30lbs |
| Flanged Cross Bar 42” | U0072729 | $7.50 | 4.98lbs |
| Flanged Cross Bar 48” | U0072731 | $8.50 | 5.66lbs |
| Col. Shield | U0108385 | $13.00 | 6.49lbs |
| 25F Shim | U0075042 | $.90 | .28lbs |
| 75F Shim | U0075045 | $1.15 | .41lbs |
| Anchor | U0074582 | $1.50 | .25lbs |
| Can Spray Paint, Green | U0074709 | $17.00 | 1.00lbs |
| Can Spray Paint, Orange | U0077720 | $17.00 | 1.00lbs |
